50kg Load Cell Bracket - Precision Weight Sensor For DIY

The sensor is a group of half-bridge strain gauge, there are 3 ways to use it : 1. Use one sensor with an external resistor to form a full-bridge measurement, the range of a sensor range: 50kg. External resistance on the higher requirements. 2.Use two sensors to form a full-bridge measurement, measuring range for the sum of the two sensors: 50kgx2 = 100kg 3.Use four sensors to form a full-bridge measurement, measuring range for the sum of four sensors: 50kgx4 = 200kg Package Includes: 4 X Human Scale Load Cell 50kg 1 X HX711 AD Module The 50kg load cell is a group of half-bridge strain gauge, there are 3 ways to use it. 2.Use two sensors to form a full-bridge measurement, measuring range for the sum of the two sensors: 50kgx2 = 100kg Use one load sensor 50kg with an external resistor to form a full-bridge measurement, the range of a sensor range: 50kg. Use four weight scale 50kg to form a full-bridge measurement, measuring range for the sum of four sensors: 50kgx4 = 200kg If you have any problem, please do as follow: click DIYmalls(you can find Sold by DIYmalls under Buy Now button), in the new page, click Ask a question.
