Force Gauge Stand, 500N Push Pull Force Test Stand, Manual Tension Test Stand With 2 Clamp For Tensile Testing Of Wires And Cables

Application It is suitable for wire terminal and solder joint removal tests, push-pull meter tests, break point tests, and such fields as rubber and plastic, the light industry, textile, building doors and windows, composite materials, and wire and cable industries for tensile experiments. Specifications Color: Black Operation: Hand-wheel Operated Material: Iron, Plastic Style: Modern Surface Treatment: Baking Paint Mount Type: Free Standing Assembly Required: Yes Maximum Tensile Strength: 500N/50kg Maximum Clamping Opening: 20mm/0.79inch Meter Installation Plate Size(L*W): 16.6*6cm/6.53*2.36inch Sliding Rail Width(Inner): 6.2cm/2.44inch Sliding Rail Width(External): 9cm/3.54inch Sliding Rail Tube Diameter: 1.44cm/0.57inch Middle Rod Diameter: 1.35cm/0.53inch Handwheel Diameter: 10cm/3.94inch Handle Length: 6.2cm/2.44inch Overall Product Size: 48*20.5*10.55cm/18.9*8.07*4.15inch Stroke: 22cm/8.66inch Packaging Size: 43*12*13cm/16.93*4.72*5.12inch Gross Weight: 6kg/13.23lbs Package Included 1* Force Gauge Stand 1* Allen Key Set 2* Clamps Notes 1. Please check the size carefully before ordering. 2. Please note that the push-pull pressure gauge is not included. 3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order. 【Excellent tensile strength】It is made of high-quality iron with a baking paint surface, high strength, and hardness, making our product sturdy and durable. Its premium material and stable construction provide it with a strong tensile strength (500N), which can meet various testing needs and you can use it confidently. 【Effortless assembly】Most of its parts are well-installed, so you just need to assemble the clamps, the round handlebar, and a force gauge (not included) and then you can start to use it. 【Easy to clean】With a simple structure and smooth surface, you can easily clean it with a damp cloth.
